Huawei S5731-S24P4X 24Port Gigabit Managed Switch
Description
The CloudEngine S5731-S series offers a range of standard gigabit access switches, with all-GE electrical/optical ports and fixed 10 GE uplink ports.
Built on Huawei’s unified Versatile Routing Platform (VRP), CloudEngine S5731-S switches provide enhanced Layer 3 features, simplified Operations & Maintenance (O&M), Intelligent Stack (iStack) technology — allowing multiple stacking-capable switches to function as a single logical switch — flexible Ethernet networking, and mature Internet Protocol version 6 (IPv6) features.
The series is widely used in a range of scenarios, including enterprise campus access and aggregation, as well as data center access.
| Item |
S5731-S24P4XÂ Specification |
|---|---|
| Model | Huawei CloudEngine S5731-S24P4X |
| Fixed Ports | 24 × 10/100/1000Base-T PoE+ ports4 × 10GE SFP+ uplink ports |
| Switching Capacity | 128 Gbps (device) / 672 Gbps (system) |
| Forwarding Rate | 96 Mpps |
| PoE Support | PoE+ supported, dual hot-swappable power supplies (AC/DC 600W or 1000W) |
| Power Consumption | Typical: 121 WMax: 977 W (720 W for PoE PD devices) |
| Dimensions (W × D × H) | 442 mm × 420 mm × 43.6 mm (1U) |
| Weight (including packaging) | Approx. 8.6 kg |
| Cooling | Front-to-rear airflow, hot-swappable fan modules |
| Management | CLI, SNMP, RMON, Web GUI, SSH, batch config, zero-touch provisioning, VRP OS |
| Layer 3 Features | OSPF, IS-IS, BGP, VRRP, RIP, Static Routing, VLAN, ACL, QoS, DHCP Snooping, 802.1X |
| IPv6 Support | Dual-stack (IPv4/IPv6), RIPng, IPv6 tunnels (ISATAP, 6-to-4, manual) |
| Stacking | iStack supported |
| Virtualization | Supports Super Virtual Fabric (SVF) |
| Application Scenarios | Ideal for enterprise campus networks, hospitals, hotels, and IP surveillance |
Indicator Description
The S5731-S24P4X has the same types of indicators as the S5731-S48P4X.
